Part Number: QTHA-2FB0-RG

G 1/4" female BSPP (ISO 228/1) x male Quick-test, no check-valve, brass

Connect Male BSPP (ISO 228/1) parallel thread to Quick-test hose for temporary installation

Request a Quote

To receive pricing, request a quote and a Ralston Distributor will respond.

Get a Quote
Download DatasheetNeed help? Contact Us

Specifications

Weight1.47 oz / 42 grams
Length1.12 in / 29 mm
Width0.75 in / 20 mm
Height0.75 in / 20 mm
Country of originUSA
MaterialsBrass
Max Operating Temperature225 °F / 105 °C
Max Pressure5000 PSI / 350 bar / 35 MPa
Max Vacuum0 InHg / 0.0 kPa
Seal MaterialsBuna-N
Wrench Size3/4 In / 20 mm
Wrench Size19 mm / 23/32 in
End 1 Connector
G 1/4 Female BSPP (ISO 228)
End 1 DirectionLeft
End 2 Connector
Male Quick-test
End 2 DirectionLeft
