Vacuum Cylinder Hand Pumps

Generate vacuum to calibrate vacuum devices in the field

  • Lightweight, compact pump generates 23 inHg (584mm Hg)vacuum with ease
  • Large volume fine adjustment piston provides precise control, even at very low vacuums
  • Modular design makes field maintenance quick and easy
  • Precisely vent pressure with soft seated bleed valve
  • Two outlet ports provide connections for both pressure reference and for device under test thus eliminating a tee
  • Low volume Quick-test hose, gauge adapter and process connection can be attached to pump without thread sealant or a wrench
  • Rugged, all metal construction reduces pressure changes due to temperature fluctuations
  • Made in U.S.A.

Vacuum Cylinder Hand Pumps

Model Pressure Reference Process Connection Reference Connection Max Pressure Max Vacuum Materials Seal Materials Min Temperature Max Temperature
DV0V-0000 None
1/4" Male NPT
None
0 PSI
23 In Hg
Anodized Aluminum
Brass
Stainless Steel
Buna-N
Delrin
Teflon
0 °F
130 °F
DV0V-1MBA None
1/4" Male NPT
1/8" Male NPT
0 PSI
23 In Hg
Anodized Aluminum
Brass
Stainless Steel
Buna-N
Delrin
Teflon
0 °F
130 °F
DV0V-2MBA None
1/4" Male NPT
1/4" Male NPT
0 PSI
23 In Hg
Anodized Aluminum
Brass
Stainless Steel
Buna-N
Delrin
Teflon
0 °F
130 °F
DV0V-2FBA       0 PSI
23 In Hg
Anodized Aluminum
Brass
Stainless Steel
Buna-N
Delrin
Teflon
0 °F
130 °F
DV0V-2FBA-RG None
1/4" Female BSPP (G1/4)
1/4" Female BSPP (G1/4)
0 PSI
23 In Hg
Anodized Aluminum
Brass
Stainless Steel
Buna-N
Delrin
Teflon
0 °F
130 °F
DV0V-3FBA-RG None
1/4" Female BSPP (G1/4)
3/8" Female BSPP (G3/8)
0 PSI
23 In Hg
Anodized Aluminum
Brass
Stainless Steel
Buna-N
Delrin
Teflon
0 °F
130 °F
DV0V-4FBA-RG None
1/4" Female BSPP (G1/4)
1/2" Female BSPP (G1/2)
0 PSI
23 In Hg
Anodized Aluminum
Brass
Stainless Steel
Buna-N
Delrin
Teflon
0 °F
130 °F
DV0V-30HG-M   1/4" Male NPT
1/4" Female NPT
0 PSI
23 In Hg
Anodized Aluminum
Brass
Stainless Steel
Buna-N
Delrin
Teflon
0 °F
130 °F
DV0V-30HG-D Digital pressure gauge, 30 PSIG Pressure
1/4" Male NPT
1/4" Female NPT
0 PSI
23 In Hg
Anodized Aluminum
Brass
Stainless Steel
Buna-N
Delrin
Teflon
0 °F
130 °F
